3W发动机
3W-110i B2 CS
| Cylinder capacity | 110.00 ccm |
| Power | 12.8 HP / 9.41 KW |
| Bore diameter | 45.00 mm |
| Stroke | 35.00 mm |
| Rpm range | 1.200 – 8.500 U/min-1 |
| Weight incl. ignition | 3.050 kg incl. ignition |
| Crankshaft | 3 ball bearing |
| Oil/gasoline ratio | 1:50 / 2% Mix |
| Ignition | 6.0 – 8.4 V DC
|
3W-80Xi CS
| Cylinder capacity | 78.00 ccm |
| Power | 9.0 HP / 6.6 KW |
| Bore diameter | 50.00 mm |
| Stroke | 40.00 mm |
| Rpm range | 1.200 – 8.500 U/min-1 |
| Weight incl. ignition | 2.375 kg incl. ignition |
| Crankshaft | 3 ball bearing |
| Oil/gasoline ratio | 1:50 / 2% Mix |
| Ignition | 6.0 – 8.4 V DC
|
3W-56i B2 CS
| Cylinder capacity | 57.0 ccm |
| Power | 4.44 HP / 4 KW |
| Rpm range | 1.500 – 8.500 U/min-1 |
| Weight incl. ignition | 1.850 kg |
| Oil/gasoline ratio | 1:50 / 2% Mix |
| Ignition | 6.0 – 8.4 V DC
|
3W-110i B2
| Cylinder capacity | 110.00 ccm |
| Power | 11.8 HP / 8.68 KW |
| Bore diameter | 45.00 mm |
| Stroke | 35.00 mm |
| Rpm range | 1.200 – 8.500 U/min-1 |
| Weight incl. ignition | 3.050 kg incl. ignition |
| Crankshaft | 3 ball bearing |
| Oil/gasoline ratio | 1:50 / 2% Mix |
| Ignition | 6.0– 8.4 V DC
|
